Product Description
Specifications:
Part Number: 309NR
Brand: SKF
Category: Deep groove ball bearings
ID MM: 45 MM
OD MM: 100 MM
W MM: 25 MM
ID Inches: 1.7716 Inches
OD Inches: 3.937 Inches
W Inches: 1.7716 Inches
EAN: 7316576680380
Seal: None. open bearing
Clearance: Normal radial clearance
Current Insulation: No current insulation
Bore: Cylindrical bore
Outer Ring: With filling slots and annular groove with circlip in outer
Temperature Range: -20 to +120 °C
Material: Standard bearing steel
Tolerance Class: Tolerance class P0/PN2 / ABEC 1
Material Of Rolling Elements: Standard bearing steel
Cage: Sheet steel
Ball Rows: Single row bearing
Product Information:
New in box 309NRSKF Deep groove ball bearings
Applications:
Deep groove ball bearings are versatile and widely used in a multitude of applications due to their ability to accommodate both radial and axial loads. Here are some common applications of deep groove ball bearings: Automotive Industry, Industrial Machinery, Electric Motors, Household Appliances, Agricultrual Machinery, Power Tools, Bicycles and Sporting Equipment, Medical Equipment, Mining and Quarrying Equipment, Renewable Energy Systems.
In summary, deep groove ball bearings are essential components in a wide range of applications across various industries, providing support for rotating shafts and components while minimizing friction and enabling smooth operation. Their versatility, reliability, and efficiency make them indispensable in modern machinery, equipment, and systems.
